[Tutorial] How To Update RGH\JTAG To Dash 16202

H2B Dec 28, 2012

  1. H2

    H2B Newbie
    0/47

    Joined:
    Dec 26, 2012
    Messages:
    113
    Likes Received:
    16
    Trophy Points:
    0
    Gender:
    Male
    Location:
    Kutztown PA
    Console:
    Xbox
    This Is A Tutorial How To Update Your Current Dash to The New 16197 And 16202

    Requirements

    RGH/JTAG
    USB Or FTP (Up To You)
    Flash360 - http://www.mediafire.../?lnfzm3rgizud9
    J Runner - http://www.mediafire...82a7iiqwyh89ywb
    Password = Whats My XPG Name?
    CPU Key - Turn On Xbox With The Eject Button Get A Blue Screen Xell It Will Load All The Way Down And You Will See A CPU Key And Drive Key.. Write Down The CPU Key
    NAND - You Get With Flash360
    Have Atleased Completed The 5th Grade


    Getting NAND
    1. Put Flash360 Folder In USB
    2. Connect USB To JTAG Open XEX menu and Open The Flash360 Folder
    3.Run Flash360 And Press (A,A) Then Back Out Of It
    4.Go Back To Xex Menu,Flash360 Folder Now You Should Have A Flashdmp.bin File

    Creating IMG
    5.Connect USB Back To PC
    6.Open J Runner (Run As Admin On Vista Or 7)
    7.Open You NAND
    [​IMG]
    7.The NAND Is The Flashdmp.bin File On The USB
    8.Windows Will Pop Up Asking What Is Your Xbox Xenon,Falcon,etc... Click Which One You Have
    9.Add A Dash
    *Click On Add Dash
    *Window Will Pop Up And Scroll Down And Click The Dash 16.197 or 16.202 And Press Add Dash

    10.Right Top Click The Console Your Updating JTAG,RGH,RGH2,etc...
    11.Add The CPU Key
    [​IMG]

    Once It Load Click On Create Image Box

    12.Once It Saids Image ready In The Black Box - You Can Close J Runner

    13.Now Go To The J Runner Folder And You Should Have A New Folder With Number
    14.Theres A File In There Called updflash.bin
    15.Put File In USB And Go Connect It Back To The Console

    Fun Starts
    16.Go To Flash360 And Run It
    17. Now Your Going To Press (A,B,START,START,A)

    VERY IMPORTENT PART
    18.Once Done Its Going To Say Press Any Key To Exit Press (B,B)
    19.Its Going To Automatically Turn Off
    20.Once Counter Hits 0 UNPLUG POWER CABLE FOR 30 SEC Yes 30 SEC Go Pee Or Something

    21.Turn On JTAG And :eek:mg2:
    You Should Be On The New Dash Congrats

    Hope This Helped

    • Like Like x 4
  2. Tattoo

    Tattoo XPG Mentor Lifetime Gold
    0/47

    Joined:
    May 13, 2012
    Messages:
    368
    Likes Received:
    71
    Trophy Points:
    0
    Gender:
    Male
    Location:
    Australia
    Console:
    Xbox
    This is a great Tut used it many times plus its real easy to mess up.

  3. batnoob

    batnoob NoooB
    0/47

    Joined:
    Jan 2, 2013
    Messages:
    23
    Likes Received:
    1
    Trophy Points:
    0
    Gender:
    Male
    Console:
    Xbox
    when i run flash360 on my rgh/jtag i get a error:'updflash.bin' not found
    do you know why i am getting this error?


    nevermind i got it pressed X then A in step 3 lol

    THANK YOU!!!!!

  4. mo

    monkeybutt852 Newbie
    0/47

    Joined:
    Aug 14, 2012
    Messages:
    6
    Likes Received:
    0
    Trophy Points:
    0
    Console:
    Xbox
    i think i messed up my jtag got the 3 rrod is there anyway to fin it pleas reply

  5. deadone

    deadone As I walk through the valley of death I shall fear Lifetime Gold
    75/94

    Joined:
    Mar 22, 2012
    Messages:
    912
    Likes Received:
    203
    Trophy Points:
    75
    Gender:
    Male
    Console:
    Xbox
    the password is not your name

  6. Pe

    PedoJuco Newbie
    0/47

    Joined:
    Mar 16, 2013
    Messages:
    0
    Likes Received:
    0
    Trophy Points:
    0
    Console:
    Playstation 3
    Password is "H2B'... (without the quotation marks)

    H2B, Thanks it worked well but now the 360 is asking for a Kinect Update when I plug the kinect in. What is the safe way to update that?

  7. Tr

    Truereligionm Newbie
    0/47

    Joined:
    Dec 18, 2012
    Messages:
    16
    Likes Received:
    1
    Trophy Points:
    0
    Console:
    Xbox
    I get an error witht the aa thing :(


    j thing doesint work wtf i click dash launch n it never saves it

  8. ra

    rayza Newbie
    0/47

    Joined:
    Jul 2, 2012
    Messages:
    2
    Likes Received:
    0
    Trophy Points:
    0
    Console:
    Xbox
    its saying that i have missing ini's
    what do i do
    thanks for anyone who can help

  9. xIIJazza

    xIIJazza Gods divine one
    0/47

    Joined:
    Jun 7, 2011
    Messages:
    548
    Likes Received:
    149
    Trophy Points:
    0
    Gender:
    Male
    Console:
    Xbox
    i thought the latest update is 16203?

    But anyway great tutorial may wanna update the "getting nand" part due to, To be able to get the nand on flash 360 you have to press x then a a :p

    Other than that, Great tutorial keep up the great work ;)

  10. pa

    pacinoallstars Member
    25/47

    Joined:
    Apr 15, 2012
    Messages:
    218
    Likes Received:
    15
    Trophy Points:
    25
    Console:
    Xbox
    just wondering why do we have to turn power off for 30 sec (yes i know it essential). but why is it essential besides bricking up the 360.

  11. be

    behdad Newbie
    0/47

    Joined:
    Sep 6, 2013
    Messages:
    1
    Likes Received:
    0
    Trophy Points:
    0
    Console:
    Xbox
    my xbox wont start when i eject my dvd drive :mad:
    it just keep making some wierd sounds and it wont start
    please someone help me :cry:

  12. Renegade

    Renegade Super Special Awesome XPG Developer
    0/47

    Joined:
    Nov 19, 2009
    Messages:
    1,212
    Likes Received:
    879
    Trophy Points:
    0
    Gender:
    Male
    Location:
    United Kingdom
    Console:
    Xbox
    Make a new thread in the support section. List everything you did before it was working.

  13. Hanzx

    Hanzx Newbie
    0/47

    Joined:
    Jun 22, 2012
    Messages:
    288
    Likes Received:
    17
    Trophy Points:
    0
    Gender:
    Male
    Console:
    Computer
  14. crabbycrabcrab

    crabbycrabcrab Lifetime Gold Lifetime Gold
    125/188

    Joined:
    Jul 8, 2012
    Messages:
    1,213
    Likes Received:
    220
    Trophy Points:
    125
    Console:
    Xbox
    How do i load Flash360 and run it. I did everything before and my xbox boots but only to nxe dashboard

  15. vl

    vladeboy Newbie
    0/47

    Joined:
    Sep 23, 2013
    Messages:
    1
    Likes Received:
    0
    Trophy Points:
    0
    Console:
    Xbox
    Hey guys, followed this tutorial after i power cycled it, it won't start up, just 3 red flashing rings. Any ideas?
