How to dump the xbox slims DVD key!

Bullet Nov 22, 2010

  1. Bu

    Bullet Guest


    Tarablinda is a collection of hacks and tricks which he discovered during hw and fw exploration (allows to extract dvdkey and more and since this last version even an experimental way to dump the whole FW).

    Download: Tarablinda v0.4b Here

    To quote: Thanks for running the test app, i figured out nothing interesting from it but thanks for doing it anyway, ehehheeh

    I had no time, no will and no more than 2 drive to test, and i'm not willing to support it too much, it's just a proof of concept. It can contain bugs and it's not an idiot proof app.

    I spent 2 months of spare night-time on this, from decapping to fullrawdump, passing by descrambling fw, reversing fw, bruteforcing, finding usefull cdb commands, bugs and tricks. This is the result, not the beginning of something else.

    Since it's my hobby, i'm free to do what i like, just enjoy it or hate it, i dont' care. Slim liteon is well detectable and also lockable to a permanent read-only SPI flash, it's just a matter of MS to push the red button.

    Tarablinda v0.4b

    Usage : Tarablinda [SATA PORT] [dump|erase|rewrite] [file to flash]
    Example: Tarablinda E480 dump
    Example: Tarablinda E480 rewrite newfw.bin

    Special: Tarablinda E480 dump full
    Experimental risky fulldump

    Tarablinda is a collection of hacks and tricks which i discovered during hw and fw exploration. It's only a proof of concept, I take no responsibility for any damage it may causes.

    I've checked on Via controller (with drivers removed) and Intel ICH7 several time, against 2 different drives with same FW revision.
    There could be different FW revision out here, it could not work for several reasons.


    it dumps the dvdkey and checks it with MS drive auth protocol,
    like the console does everytime you poweron, so it's good for sure.
    It's not a destructive/invasive dump.

    It dumps also serials (1FFE0 area)
    It also dumps the whole dvdkeyarea, included the latest 0x10 bytes of such area, which are unique per drive too.
    It also dumps sectors 3Dxxx 3Exxx

    Dummy.bin is nothing else than a blank file with dvdkeyarea, 3D000-3EFFF and serials in place, not jf compatible.


    dump full:
    Like above, then checks if 3D-3E sectors are the known ones, rewrites 3E with patched code to make the fw send us the full dump.
    It's a little risky cause we can't know for sure if the dumped 3D-3E sectors are really that sector numbers.
    Since scrambling the same data at different addrress results in different scrambled data, we can be quite sure.
    But again, this is beta software and consider you are risking on your own, it's your choice.

    Erase and Rewrite(which is an erase+write) are mainly for studying purpose
    Unless you have a full dump of your drive,
    erase and rewrite are not recommended for the most

    Special thanks to Kai Schtrom - Maximus - TeamModFreaks

    As usual, use at your own risk
